Barber Electric “Type 3R Screw Cover Enclosures” are designed for use as junction boxes and wiring boxes in outdoor installations. They are designed to protect the enclosed equipment against rain and sleet.

These enclosures are made from 16, 14 and 12 gauge steel. A drip shield top and smooth seamless sides prevent rain, snow, or sleet from entering the enclosure. Emboss mounted holes are located in the back. The standard finish for these enclosures is ANSI 61 gray polyester powder coat.

Barber Electric can supply holes, hubs, louvers, cutouts, special finishes, and many other modifications to these enclosures.

PDF (Click thumbnail to view full size):


Catalog #
Size (A x B x C)

B664RTC
6 x 6 x 4
B884RTC
8 x 8 x 4
B10104RTC
10 x 10 x 4
B12124RTC
12 x 12 x 4
B886RTC
8 x 8 x 6
B10106RTC
10 x 10 x 6
B12126RTC
12 x 12 x 6
B18186RTC
18 x 18 x 6
B12128RTC
12 x 12 x 8
B18188RTC
18 x 18 x 8




Interactive 3D PDF (Click thumbnail to view and interact):
