Barber Electric “Type 12 Flush Mount Enclosures” are designed to house electrical controls and instruments. They provide protection from dust, dirt, oil, and water.

These enclosures are made from 14 gauge steel and have a strong, rigid construction. All seams are continuously welded and there are no holes or knockouts. A rolled lip is provided around all sides of the enclosure opening. This lip increases strength and keeps dirt and liquids from dropping into the enclosure when the door is opened. Captivated door screws secure the gasketed door and can be operated with a screwdriver. A heavy 12 gauge mounting frame extends around the enclosures. Collar studs are provided for mounting the optional panel. Panels must be ordered separately.

The standard finish for these enclosures is ANSI 61 gray polyester powder coat. Barber Electric can provide hubs, louvers, cutouts, special finishes, special sizes, and many other modifications.

PDF (Click thumbnail to view full size):


Catalog #
Size (A x B x C)
Panel Size

17B16126FM
16 x 12 x 6
13 x 9
17B20166FM
20 x 16 x 6
17 x 13
17B20206FM
20 x 20 x 6
17 x 17
17B24246FM
24 x 24 x 6
21 x 21
17B20168FM
20 x 16 x 8
17 x 13
17B24248FM
24 x 24 x 8
21 x 21
17B30308FM
30 x 30 x 8
27 x 27


Interactive 3D PDF (Click thumbnail to view and interact):
