Barber Electric “Type 12 Two Door Wall Mounted Enclosures” are designed to house electrical controls and instruments. They provide protection from dust, dirt, oil, and water.

These enclosures are made from 14 gauge steel. All seams are continuously welded and there are no holes or knockouts. A rolled lip is provided around two sides of each door and around all sides of the enclosure opening. This increases strength and keeps dirt and liquid from dropping into the enclosure when the door is opened. These enclosures have overlapping doors which eliminate the need for a center post. A 3-point latching mechanism, operated by a key-locking handle, holds the doors securely closed. There are rollers on the latch rods for easier door closing. Heavy gauge continuous hinges support each door. Body stiffeners are provided in larger enclosures. Four or six external feet are furnished for mounting. Collar studs are provided for mounting the option panels. Panels must be ordered separately.

The standard finish for these enclosures is ANSI 61 gray polyester powder coat. Barber Electric can provide hubs, louvers, cutouts, special finishes, special sizes, and many other modifications.

PDF (Click thumbnail to view full size):


Catalog #
Size (A x B x C)
Panel Size

9B24428LP
24 x 42 x 8
21 x 39
9B24488LP
24 x 48 x 8
21 x 45
9B304210LP
30 x 42 x 10
27 x 39
9B304810LP
30 x 48 x 10
27 x 45
9B306010LP
30 x 60 x 10
27 x 57
9B364212LP
36 x 42 x 12
33 x 39
9B364812LP
36 x 48 x 12
33 x 45
9B366012LP
36 x 60 x 12
33 x 57
9B367212LP
36 x 72 x 12
33 x 69
